3/4″ Dryfreight Wood Door

CNC machining of wood panels ensures accurate alignment of hinges and door hardware and eliminates gaps between panels for reliable trouble free operation. Diamond custom designs and manufactures its roll up door products to suit customer requirements. This ensures a personalized service and high quality fit for purpose product.

Size:

Custom made doors from 30″ to 98 1/4″ wide x 48″ to 120″ high.

Technical Information

1 of 6

Features

  • 7 ply, 3/4″ top quality, medium density overlaid hardwood/Douglas FIR faced plywood with Douglas FIR/Hemlock inner layers manufactured with a 2 step layup and waterproof glue bond.
  • Pre-painted white or primed finishes available.
  • 2″ galvanized steel track and 1″ steel rollers.
  • Tongue-and-groove or ship lap joints.
  • Head, bottom, and side seals provide protection against water and dirt penetration.
  • 2 cable, spring counterbalance with independent spring for each cable. Springs treated with rust preventative.
  • 4 rows of hinges.
  • Pavco coated steel rivets.
  • 77 style lock, lifting handle and HD 18″ looped pull strap provided.
  • All door hardware is E-COATED
